MBMet Range of Weather Sensors

Wind Speed & Direction Sensor - MBMet-130

MBMet‑130 is a high-precision, dual-parameter wind sensor

The MBMet‑130 is a high-precision, dual-parameter wind sensor designed to measure both horizontal wind speed and wind direction in a single compact unit. It combines a durable 3-cup anemometer and a 360° wind vane mounted on the same vertical axis, offering consistent and synchronized wind data from a single point of installation. This architecture simplifies deployment while ensuring accuracy and reliability in various industrial and meteorological applications.
Constructed using carbon-fiber reinforced plastic and aluminum alloy, and rated IP65, the MBMet‑130 is engineered for harsh weather conditions and long-term outdoor exposure. With options for both analog (4–20 mA) and digital RS‑485 Modbus RTU output formats, it integrates seamlessly with modern SCADA systems, data loggers, and weather monitoring platforms.

Benefits & Features

Combined measurement of wind speed and direction in a single sensor
Low starting threshold of 0.5 m/s enables early wind detection
Available with industry-standard 4–20 mA analog or RS‑485 Modbus output
Wind speed range up to 45 m/s (Analog) or 70 m/s (Modbus)
High survivability: withstands gusts up to 75 m/s
Wind speed range up to 45 m/s (Analog) or 70 m/s (Modbus)
Wind direction accuracy within ±3°, with 1° resolution
IP65-rated enclosure protects against dust and rain
Operates reliably from –40°C to +70°C
Includes stainless steel pole mounting bracket
Low power consumption: approx. 0.3 W
Lightweight and compact design for versatile field use

Technical Specifications

Category	Parameter	MBMet-130-A (Analog 4–20 mA)	MBMet-130-B (RS-485 \| Modbus RTU)
Wind Speed	Measurement Range	0 to 45 m/s	0 to 70 m/s
	Accuracy	±3% of reading	±3% of reading
	Resolution	0.1 m/s	0.1 m/s
Wind Direction	Start Threshold	0.5 m/s	0.5 m/s
	Survival Wind Speed	75 m/s	75 m/s
	Measurement Range	0 to 360°	0 to 360°
	Accuracy	±3°	±3°
	Resolution	1°	1°
Electrical	Output Signal	4–20 mA	RS-485 Modbus RTU
	Power Supply	12–24 VDC	12–24 VDC
	Power Consumption	< 0.3 W	< 0.3 W
Mechanical	Housing Material	Carbon-Fiber + Aluminum Alloy	Same
	Enclosure Rating	IP65	IP65
	Dimensions	As per standard assembly	As per standard assembly
	Weight	Approx. 700 g	Approx. 700 g
	Mounting	Pole Mount Bracket (included)	Same
Environmental	Operating Temperature	–40°C to +70°C	–40°C to +70°C
	Operating Humidity	0 to 100% RH	0 to 100% RH
