Multifunction Power Meter - PM135
Multi-function Power Meter with LCD Display
-
IEC 62053-22
-
IEC 61557-12
-
-
-
-
Multi-function Power Meter
The PM135 is a multifunctional three-phase power meter.
Featuring versatile I/O options, communication ports and protocols, it is
ideal for integration in utility substations or industrial SCADA systems.
An LCD display, accompanied by a LED load-bar, enables easy on-site access
to power parameters and viewing of load percentage at a glance.
Benefits & Features
- Accuracy: Class 0.5/0.5S per ANSI / IEC 62053-22
- Built-in: RS485
- Optional ports: ETH; Wi-Fi; cellular; Profibus
- Open protocol: Modbus RTU; DNP3.0
- IEC 60870-5-101/104
- Digital & Analog I/O up to 16 I/O
- Voltage: 15-828V AC (direct, L-L)
- Frequency: 25, 50, 60, 400 Hz
- Multi-option AC Current Inputs 5A or 1A
- Multi-option AC Current Inputs 40mA for HACS CTs (100-3,000A)
- Special input: clip-on 5A HACS for retrofit
| Accuracy | |
|---|---|
| Class 0.5/0.5S accuracy per ANSI C12.20 / IEC 62053-22 | |
| Class 0.2 per IEC 61557-12 | |
| Power Meter | |
|---|---|
| Voltage, current (including neutral current), power, energy, power factor, frequency, voltage/current unbalance | |
| Ampere/Volt demand meter | |
| 25, 50, 60 and 400 Hz measurements | |
| Sampling frequency: 128 samples per cycle | |
| Variable Current Inputs | |
|---|---|
| 5A | |
| 1A | |
| HACS: special 40mA inputs for SATEC’s High Accuracy Current Sensors | |
| Shunt compatibility for DC metering | |
| RS5: Special 5A input for 5A clip-on HACS for retrofit installation on existing MV/HV CT secondary. | |
| Harmonic Analyzer | |
|---|---|
| Voltage and current THD, TDD and K-Factor, | |
| Voltage and current harmonic spectrum and angles, up to the 40th order harmonic | |
| Modular I/O | |
|---|---|
| 4 Digital Inputs + 2 digital outputs (SSR or EM) | |
| 12 Digital Inputs + 4 Digital Outputs (including additional com port of choice) | |
| 8 Digital Inputs | |
| 4 Analog Outputs (for Smart Transducer application) | |
| Programmable Logical Controller | |
|---|---|
| Embedded programmable controller | |
| 16 control set points; programmable thresholds and delays | |
| Relay output control (for alarm and protection) | |
| 1-cycle response time | |
| Communication Protocols | |
|---|---|
| Modbus RTU/TCP | |
| ASCII | |
| DNP 3.0/TCP | |
| IEC 60870-5-101/104 | |
| Power Supply | |
|---|---|
| Auxiliary multi-purpose AC/DC power supply (85-265V AC, 88-290V DC) | |
| Special versions (12, 24-48V DC) | |
| Meter Security | |
|---|---|
| Three-level Password security for protecting meter setups and accumulated data from unauthorized changes. | |
| Display | |
|---|---|
| 3×2” / 76x49mm backlit LCD display | |
| Adjustable display brightness and update rate | |
| Auto-scroll option with adjustable page; autoreturn to a default page | |
| LED bar-graph displaying load as percentage of | |
| nominal load current (user-definable) | |
| Programmable Logical Controller | |
|---|---|
| Embedded programmable controller | |
| 16 control set points; programmable thresholds and delays | |
| Relay output control (for alarm and protection) | |
| 1-cycle response time | |
| Power Supply | |
|---|---|
| Auxiliary multi-purpose AC/DC power supply (85-265V AC, 88-290V DC) | |
| Special versions (12, 24-48V DC) | |
| Communication Interfaces | |
|---|---|
| Built-in: | |
| Standard 2-wire RS-485 | |
| Add-on Com Modules (1 per device): | |
| Multipurpose RS-232/422/485 port | |
| ETH 10/100Base-T | |
| PROFIBUS | |
| Wi-Fi module | |
| Real Time Clock & TOU | |
|---|---|
| Clock and calendar functions | |
| Time-of-Use billing and logging: | |
| 4 totalization and tariff energy/demand registers x 8 tariffs, 4 seasons x 4 types of days, 8 tariff changes per day | |
| 2 year battery backup | |
| Mounting | |
|---|---|
| 92×92mm square | |
| 4” round cutout | |
| Current Input Rating Options | |
|---|---|
| 5A for CT secondary | |
| 1A for CT secondary | |
| 40mA input for HACS remote CTs | |
| RS5: 5A split core HACS remote sensor (50/60Hz only) | |
