The MBP-100 Dual SIM Cellular Communication Router is designed to provide Secure and Reliable Connectivity for Remote Locations. With Cellular (2G - 5G), and Ethernet connectivity and additional Features such as VPN Support, Multiple WAN Access Methods, FTP the MBP-100 Cellular Router is ideal for a Large range of Applications such as Renewable Energy, Electrical Utilities, Sub-Stations, Telemetry, Smart Cities, etc.
| Cellular Standards | |
|---|---|
| Standards and Frequency Bands | LTE-FDD 2600 / 2100 / 1800 / 800 MHz, 700 / 1700 / 2100 MHz DC-HSPA+ / HSPA+ / HSDPA / HSUPA / UMTS 850 / 900 / 2100 MHz EDGE / GPRS / GSM 850 / 900 / 1800 / 1900 MHz GPRS Class 10 GPRS Class 12 |
| Bandwidth | LTE FDD: Downlink: 100 Mbps, Uplink: 50 Mbps DC-HSPA+: Downlink: 42 Mbps, Uplink: 5.76 Mbps HSPA+: Downlink: 21 Mbps, Uplink: 5.76 Mbps HSDPA: Downlink: 7.2 Mbps, Uplink: 5.76 Mbps UMTS: 384 Kbps |
| Transmit Power | < 23 dBm |
| Receiver Sensitivity | > -97 dBm |
| Power, Hardware, and Interfaces | |
|---|---|
| CPU | Industrial Grade 32 Bit Processor |
| FLASH | 16 MB |
| DDR2 | 128 MB |
| Power Supply | 5 - 36 VDC |
| Standby Power Consumption | 83 mA @ 12 VDC |
| Communication Power Consumption | 150 mA @ 12 VDC |
| Button | Reset Button |
| SIM / UIM | 1 Standard SIM Card Interface. 1.8V / 3V SIM / UIM Card 15 KV ESD Protection |
| Indicator Light | 1 Power 1 System 1 SIM 1 Online 1 Ethernet 1 Signal Strength |
| Serial Ports | 1 RS232 / RS485 Port Data Bits: 5, 6, 7, 8 Bits Stop Bits: 1, 1.5, 2 Bits Parity: No Parity, Even Parity, Odd Parity Baud Rate: 2400 - 115200 |
| WAN / LAN | 1 x 10 / 100 Mbps Ethernet Port Adaptive MDI / MDIX 15KV ESD Protection |
| Network Protocols | |
|---|---|
| WAN | Static IP, DHCP, PPPOE, 2G / 3G / 4G / 5G |
| VPN Client | PPTP, L2TP, IPSEC, OPENVPN, GRE |
| VPN Server | PPTP, L2TP, IPSEC, OPENVPN, GRE |
| Configuration | Remote Management, SYSLOG, SNMP, TELNET, SSHD, HTTPS, HTTP |
| Network Protocols | TCP/IP UDP HTTP, HTTPS NTP TELNET DDNS APN / VPDN DHCP Server / Client ICMP SMTP POP3 OICQ SSHD |
| Security | SPI Firewall VPN Traversal Access Control URL Filtering, etc. |
| Others | DHCP Binding MAC Address, DDNS, Firewall, NAT, DMZ Host, QOS, Traffic Statistics, Real-Time Display of Data Transmission Rate, Network Data Trigger Online / Offline |
| Physical Properties | |
|---|---|
| Dimensions | 100 x 97 x 25 mm (Not including Antenna + Mounting) |
| Weight | Approx. 320g |
| Operating Temperature | -35°C to +75°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 95% RH (Non Condensing) |
